- Small, long-stroke 1-speed universal magnetic core drill with forward/reverse rotation and permanent magnet for safe, fail-safe working at height.
- Narrow permanent magnet requires zero electrical power for magnetic adhesion, eliminating drop hazards caused by power failure.
- Magnetic bias / pre-magnetization enables easy, precise positioning and alignment on vertical and overhead surfaces before full clamping.
- Durable 1,010 W motor with tacho electronics delivers stable cutting speed and high torque under heavy continuous loads.
- Full operational versatility: core drilling, twist drilling, tapping up to 1/2", countersinking, and reaming with forward/reverse rotation and electronic speed control.
- Tool-free 3/4" straight shank / Weldon rapid change system allows fast, effortless cutter swaps without wrenches.
- Generous total stroke range of 10-1/4 in (260 mm) with double drill motor guide rails accommodates extra-long twist drills and reamers.
- Integrated tilt sensor automatically cuts motor power immediately if the tool shifts or loses base adhesion.
- Pivoting motor cable protection sleeve protects electrical wiring from snagging or tearing on structural edges.
Technical Data
| Max. Core Drill Dia. | 1-3/8 in (35 mm) |
| Max. Drilling Depth | 2 in (50 mm) |
| Twist Drill Max. Dia. | 5/8 in (16 mm) |
| Tapping Max. | 1/2 in (M12) |
| Countersinking Max. Dia. | 1-1/4 in (31 mm) |
| Reaming Max. Dia. | 5/8 in (16 mm) |
| Cutter Arbor | 3/4 in Straight Shank / Weldon (Tool-free) |
| Power Consumption | 1,010 W |
| Power Output | 550 W |
| Full Load Speed | 130 – 520 RPM |
| Stroke Length | 5-5/16 in (135 mm) |
| Total Stroke Range | 10-1/4 in (260 mm) |
| Magnetic Holding Force | 2,023 lbs (9,000 N) Permanent Magnet |
| Magnetic Base Dimensions | 7-11/16 x 2-3/4 in (195 x 70 mm) |
| Cable with Plug | 13.1 ft (4.0 m) |
| Weight (EPTA) | 27.56 lbs (12.5 kg) |
Price Includes
- 1 JMU 137 PQW Universal Magnetic Core Drill Unit
- 1 Coolant Tank with Hose & Brass Shutoff
- 1 Safety Lashing Strap
- 1 Centering / Pilot Pin (105 mm)
- 1 Chip Hook
- 1 Swarf / Chip Protection Guard
- 1 Drift Ejector Key
- 1 Heavy-Duty Transport / Storage Case
