Authorized Partner✔ Official Partner & Authorized Distributor
As an authorized distributor, we supply 100% genuine FEIN machinery, annular cutters, and accessories backed by the official manufacturer warranty and direct factory support.
■ 3-Year FEIN PLUS Warranty: Eligible for extended factory warranty coverage.
■ Made for Metal: Engineered for continuous heavy-duty industrial holemaking.
■ Factory Certified: 100% original equipment, full factory support, never grey-market.
Details
- Complete compact magnetic base drilling bundle featuring premium Carbide (TCT) annular cutters for structural steel, bridge work, and abrasive alloys.
- Ultra-low construction clearance height of only 6-5/8 in (169 mm) enables holemaking in tight structural cavities and narrow vehicle chassis.
- Powerful, wear-resistant 1,100 W brushless motor delivers high torque and constant cutting speed under continuous heavy load.
- Forward and reverse rotation with electronic variable speed control accommodates core drilling, twist drilling, countersinking, and tapping.
- Space-saving ratchet feed handle with combined 1/2" square drive and 8 mm hex socket operates easily from either side or in cramped quarters.
- High magnetic holding force of 2,248 lbs with an integrated tilt sensor safety shutoff that immediately cuts motor power if base adhesion shifts.
- Comprehensive job-site package includes 5 Carbide / TCT annular cutters (1" depth), centering pins, a Magbrush chip collector, cutting paste, and a stackable dual L-BOXX carrying system.
Technical Data
| Max. Carbide / TCT Cutter Dia. | 1-3/8 in (35 mm) |
| Max. HSS Cutter Dia. | 1-3/8 in (35 mm) |
| Max. Drilling Depth | 1-3/8 in (35 mm) |
| Twist Drill Max. Dia. | 3/4 in (18 mm) |
| Tapping Max. | 3/8 in (M10) |
| Countersinking Max. Dia. | 1-1/4 in (32 mm) |
| Cutter Holder / Arbor | 3/4 in Straight Shank (Weldon) |
| Motor Type | Brushless |
| Power Consumption | 1,100 W |
| Power Output | 550 W |
| Full Load Speed | 130 – 520 RPM |
| Stroke Length | 1-13/16 in (46 mm) |
| Construction Clearance Height | 6-5/8 in (169 mm) |
| Overall Length | 11-7/16 in (290 mm) |
| Magnetic Holding Force | 2,248 lbs (10,000 N) |
| Magnetic Base Dimensions | 6-7/8 x 3-1/8 in (175 x 80 mm) |
| Cable with Plug | 13.1 ft (4.0 m) |
| Drill Weight (EPTA) | 18.74 lbs (8.5 kg) |
Price Includes
- 1 JMC Magforce 90 Compact Magnetic Base Drill Unit
- 1 1/2 in Ratchet Handle
- 1 1/2 in Socket Wrench Extension
- 1 Coolant Hand Pump & Hose
- 1 Safety Lashing Strap
- 1 Chip Hook
- 1 Swarf / Chip Protection Guard
- 1 Auxiliary Transport Handle
- 1 Centering Pin (3/16 x 3-1/8 in / 4.75 x 80 mm)
- 1 Centering Pin (1/4 x 3-1/4 in / 6.35 x 82 mm)
- 1 Hex Key (5 mm)
- 1 Hex Socket Key with T-Grip (5 mm)
- 1 Plastic Carrying Case (L-BOXX 238)
- 5 Carbide / TCT Annular Cutters, 1 in depth (9/16", 11/16", 13/16", 15/16", 1-1/16" dia.)
- 2 Additional Centering Pins (1/4 x 3-1/4 in / 6.35 x 82 mm)
- 1 FEIN Magbrush Magnetic Chip Remover
- 1 Tube Jancy / Slugger Cutting Paste
- 1 L-BOXX 136 Accessory Storage Case
Factory Direct SupportCentralized Hub
FEIN Repair
Here at FEIN, we are dedicated to outstanding customer service and efficiency. As part of this ongoing commitment to excellence, FEIN sends all repairs to our Davenport, Iowa facility. As a benefit to our valued customers, our manufacturing, logistics, training and repair parts and services will be located in one central location. The unification of these departments will deliver faster repair turnaround times, which means you, our esteemed customer, can get back to work sooner.
- + Repairs performed by qualified experts.
- + Fast turnaround times.
- + Large inventory of parts.
- + 6-month warranty on repaired parts.
- + Lubrication of bearings and gearboxes.
