Details
- High-speed Endurance magnetic base drilling set configured for structural steel fabricators, optimized for carbide (TCT) annular cutters to maximize job-site productivity.
- Specially tuned high-speed gearing delivers optimal cutting speed for carbide cutters, significantly reducing cycle times compared to standard mag drills.
- Powerful, wear-resistant 1,200 W motor with constant speed electronics maintains high cutting RPM and steady feed rates under heavy loads.
- Morse-free direct 3/4" Weldon arbor delivers high concentricity, rigid cutter seating, and dependable slug ejection.
- Internal motor wiring routing protects electrical lines from snagging, tearing, and abrasive steel chips.
- Digital magnetic holding force indicator and integrated tilt sensor safety shutoff verify base clamping and immediately kill power if adhesion is compromised.
- Through-spindle internal cooling system delivers lubricant directly to the cutting edge to extend carbide cutter life.
- Complete fabrication bundle includes premium Carbide / TCT annular cutters, centering pins, a FEIN Magbrush chip collector, cutting paste, and a stackable modular storage case.
Technical Data
| Max. Carbide Cutter Dia. | 1-1/2 in (38 mm) |
| Max. Drilling Depth | 2 in (50 mm) |
| Cutter Arbor / Holder | 3/4 in Straight Shank (Weldon) |
| Power Consumption | 1,200 W |
| Power Output | 680 W |
| Full Load Speed | 620 RPM |
| No Load Speed | 720 RPM |
| Stroke Length | 3-9/16 in (90 mm) |
| Total Stroke Range | 10-1/4 in (260 mm) |
| Magnetic Holding Force | 2,248 lbs (10,000 N) |
| Magnetic Base Dimensions | 6-7/8 x 3-1/8 in (175 x 80 mm) |
| Cable with Plug | 13.1 ft (4.0 m) |
| Drill Weight (EPTA) | 23.81 lbs (10.8 kg) |
Price Includes
- 1 JME MagSpeed 150 Magnetic Core Drill Unit
- 1 Coolant Tank with Hose & Brass Shutoff
- 1 Safety Lashing Strap
- 1 Chip Hook
- 1 Swarf / Chip Protection Guard
- 1 Hex Key (5 mm)
- 5 Carbide / TCT Annular Cutters, 2 in depth (9/16", 11/16", 13/16", 15/16", 1-1/16" dia.)
- 2 Centering / Pilot Pins (1/4 x 4 in / 6.35 x 100 mm)
- 1 FEIN Magbrush Magnetic Chip Remover
- 1 Tube Slugger Cutting Paste
- 1 Heavy-Duty Drill Transport Case
- 1 L-BOXX 136 Accessory Storage Case
