Authorized Partner✔ Official Partner & Authorized Distributor
As an authorized distributor, we supply 100% genuine FEIN machinery, annular cutters, and accessories backed by the official manufacturer warranty and direct factory support.
■ 3-Year FEIN PLUS Warranty: Eligible for extended factory warranty coverage.
■ Made for Metal: Engineered for continuous heavy-duty industrial holemaking.
■ Factory Certified: 100% original equipment, full factory support, never grey-market.
Details
- Mechanical 2-speed gearbox with optimum speed adjustment for a wide range of uses.
- FEIN high performance motor with excellent speed stability for steady drilling progress in practically every application.
- Torsion-free, barrel-type motor housing with metal gear head for superb service life.
- Forward/reverse running and electronic speed preselection.
- Speed-controlled tacho electronics.
- Precision metal 3-jaw chuck.
- High concentricity.
- Retracting chuck jaws.
- Spade handle for optimal power transfer.
- Electronic start.
- Torque slip clutch.
Technical Data
- Power consumption: 1,200 W
- Power output: 680 W
- Full load speed: 0 - 520 / 0 - 1,600 rpm
- No load speed: 0 - 520 / 0 - 1,600 rpm
- Torque at maximum output power: 443 [50] / 142 [16] in/lbs[Nm]
- Stall/blocking torque: 443 [50] / 142 [16] in/lbs[Nm]
- Chuck capacity: 1/8 [3] - 5/8 [16] in[mm]
- Capacity in steel Ø: 5/8 [16] in[mm]
- Capacity in stainless steel Ø: 5/8 [16] in[mm]
- Capacity in light alloy Ø: 3/4 [20] in[mm]
- Capacity in wood Ø: 1-31/32 [50] in[mm]
- Steel hole saw diameter max: 3-1/4 [80] in[mm]
- Tapping: 1/2 in [M 12]
- Max. countersinking dia.: 1-1/4 [31] in[mm]
- Drill shaft thread: 1/2 in-20 UNF
- Minimum clearance: 1-1/16 [27] in[mm]
- Cable with plug: 13.1 [4] ft[m]
- Weight: 8.16 [3.70] lbs[kg]
Price Includes
- 1 Supra SKE single-collar, metal fast-acting 3-jaw chuck
- 1 handle
Factory Direct SupportCentralized Hub
FEIN Repair
Here at FEIN, we are dedicated to outstanding customer service and efficiency. As part of this ongoing commitment to excellence, FEIN sends all repairs to our Davenport, Iowa facility. As a benefit to our valued customers, our manufacturing, logistics, training and repair parts and services will be located in one central location. The unification of these departments will deliver faster repair turnaround times, which means you, our esteemed customer, can get back to work sooner.
- + Repairs performed by qualified experts.
- + Fast turnaround times.
- + Large inventory of parts.
- + 6-month warranty on repaired parts.
- + Lubrication of bearings and gearboxes.
