Details
- Flat, slim design requiring little clearance in corners, for installation work, even in tight locations and in corners.
- FEIN high performance motor with excellent speed stability for steady drilling progress in practically every application.
- Torsion-free, barrel-type motor housing with metal gear head for superb service life.
- Reversible.
- Precision metal 3-jaw chuck.
- High concentricity.
- Retracting chuck jaws.
- FEIN Sensitive Handle.
- Electronic start.
- 16 ft. [5 m] cable.
- 1-11/16 [43] in[mm] collar diameter for use in drill jigs.
Technical Data
- Power consumption: 500 W
- Power output: 270 W
- Full load speed: 0 - 900 rpm
- No load speed: 0 - 1,500 rpm
- Torque at maximum output power: 80 [9] in/lbs[Nm]
- Stall/ blocking torque: 212 [24] in/lbs[Nm]
- Chuck capacity: 1/16 [1.5] - 1/2 [13] in[mm]
- Twist drill diameter capacity in steel: 13/32 [10] in[mm]
- Capacity in stainless steel Ø: 1/2 [10] in[mm]
- Capacity in light alloy Ø: 1/2 [15] in[mm]
- Holesaw diameter capacity in wood: 1-3/16 [30] in[mm]
- Tapping: M 6
- Drill shaft thread: 1/2 in-20 UNF
- Clamping neck: 1-3/4 [43] in[mm]
- Minimum clearance: 7/8 [23] in[mm]
- Cable with plug: 16.4 [5] ft[m]
- Weight: 3.97 [1.80] lbs[kg]
Price Includes
- 1 Supra SKE single-collar, metal fast-acting 3-jaw chuck
- 1 handle
