Hougen HMD905 Magnetic Drill 2 Speed Coolant - 115V 0905102

Save 10% Save 10%
Original price $ 1,825.00
Original price $ 1,825.00 - Original price $ 1,825.00
Original price $ 1,825.00
Current price $ 1,642.00
$ 1,642.00 - $ 1,642.00
Current price $ 1,642.00

Individual Annular Cutters

  • "12,000-Series" Annular Cutters 3" - 6 " DOC (Pilots are not included)
  • RotaLoc and RotaLoc Plus Annular Cutters (Pilots are not included)
  • Copperhead Carbide Tip Annular Cutters (Pilots are not included)

A powerful two speed mag drill with great power to weight ratio.

• Large 2" x 2" capacity
• Powerful high torque Hougen motor and gears
• Two Speed gear box - 250 & 450 RPM
• Pilot light
• Two stage magnet - 30% increase in power when
  motor is turned on
• Positive slug ejection
• Integrated coolant bottle
• Many accessories are available for a
  portable machine shop including: drill
  chucks, tapping, countersink, and more...
• Feed handles quickly change from side to side
• Lift detector safety system
• Rear mounted controls
• Carrying case included
• Two year warranty

HMD905 SPECIFICATIONS

Electrical System
115V, 50/60 Hz - 10A, 1150W
Motor
9A (115V), 250/450 RPM
Diameter
7/16"- 2" (12mm - 50mm)
Depth
2" (50mm)
Cutter/Mount
"12,000-Series" & Copperhead™ Carbide cutters, 3/4" shank
Dimensions
22-13/16" H x 7-11/16" W x 11-3/4" L (579mm H x 195mm W x 299mm L)
Swivel Area
1-1/8" W x 1-3/8" L (28.5mm H x 34.9mm W)
Magnet
Base 3-1/8" W x 6-9/16" L (79mm W x 167mm L)
1" Plate (25mm) Dead Lift 1750 lb. (794 kg)  Drillpoint Breakaway 995 lb. (452 kg)
3/8" Plate (9.5mm) Dead Lift 1310 lb. (594 kg)  Drillpoint Breakaway 710 lb. (322 kg)
Weight
35 lb. (15.9 kg) • Shipping 52 lb (23.6 kg)
Shipping Dimensions
20 x 9.25 x 28.25" (50.8 x 23.5 x 71.8 cm)
Request a quote
SKU 905102
