Hougen HMD904 Magnetic Drill Fabricators Kit Fractional - 115V 0904105

Hougen HMD904 Magnetic Drill Fabricators Kit Fractional - 115V 0904105

Authorized Hougen Distributor Made in the USA Fast Shipping Genuine Hougen Parts Expert Tool Support
SKU 0904105
by Hougen Mfg.
$ 1,674.55
$ 1,674.55 - $ 1,674.55
$ 1,674.55
$ 1,507.00
$ 1,507.00 - $ 1,507.00
$ 1,507.00

Accessories

Hougen 08186 CHUCK ADAPTER 1/2" (HMD904, 905 & 927) SLOT DRIVE
$ 46.85 - $ 46.85
$ 46.85
$ 46.85
$ 46.85 - $ 46.85
$ 46.85

Hougen 08186 CHUCK ADAPTER 1/2" (HMD904, 905 & 927) SLOT DRIVE

Hougen Mfg.

CHUCK ADAPTER 1/2" (HMD904, 905 & 927) SLOT DRIVE

$ 46.85 - $ 46.85
$ 46.85
$ 46.85
$ 46.85 - $ 46.85
$ 46.85
Hougen 10731 1/2" HOUGEN CHUCK
$ 74.80 - $ 74.80
$ 74.80
$ 74.80
$ 74.80 - $ 74.80
$ 74.80

Hougen 10731 1/2" HOUGEN CHUCK

Hougen Mfg.

1/2" Chuck & Key for HMD904, HMD914 and HMD925

$ 74.80 - $ 74.80
$ 74.80
$ 74.80
$ 74.80 - $ 74.80
$ 74.80
$ 104.75 - $ 104.75
$ 104.75
$ 104.89
$ 104.89 - $ 104.89
$ 104.89

Hougen 04550 HMD904 Replacement Carrying Case - Hex Arbor - Replace by Hougen 09202 HMD904

Hougen Mfg.

CASE-CARRYING W/LABEL HMD904 You will recevice Hougen 09202 HMD904, this case is the replacement.

$ 104.75 - $ 104.75
$ 104.75
$ 104.89
$ 104.89 - $ 104.89
$ 104.89
Hougen 03845 KIT-TWIST DRILL & ARBOR ADAPT.
$ 150.00 - $ 150.00
$ 150.00
$ 150.00
$ 150.00 - $ 150.00
$ 150.00

Hougen 03845 KIT-TWIST DRILL & ARBOR ADAPT.

Hougen Mfg.

KIT-TWIST DRILL & ARBOR ADAPT.

$ 150.00 - $ 150.00
$ 150.00
$ 150.00
$ 150.00 - $ 150.00
$ 150.00
Hougen 10737 HOUGEN CHUCK 5/8"
$ 105.00 - $ 105.00
$ 105.00
$ 105.00
$ 105.00 - $ 105.00
$ 105.00

Hougen 10737 HOUGEN CHUCK 5/8"

Hougen Mfg.

HOUGEN CHUCK 5/8"

$ 105.00 - $ 105.00
$ 105.00
$ 105.00
$ 105.00 - $ 105.00
$ 105.00
Shop collection

Overview

HMD904 Magnetic Drill

The drill of choice for fabrication. Lightweight, powerful, & versatile.
  • Hidden motor cord
  • Increased safety with less maintenance
  • Lower overall height
  • Pilot light for low light conditions and greater hole accuracy
  • Two stage magnet. Engages full power only when motor is turned on which increases magnet life
  • Slot drive arbor system with positive slug ejection
  • Many accessories are available for a portable machine shop including: drill chucks, tapping, countersink, and more...
  • Lift detector safety system
  • Gravity fed coolant system
  • Carrying case included (09202)
  • Two year warranty
Made in USA

Made in USA

Proudly manufactured in the United States for superior quality, durability, and reliability in demanding industrial environments.
Heavy Duty Housing

Heavy Duty Housing

Durable industrial housing protects internal components in demanding jobsite environments.
Gear Shift

Gear Shift

Two-speed gearbox allows optimal torque and cutting speed for different hole sizes.
Wrench Holder

Wrench Holder

Integrated wrench holder keeps adjustment tools secure and easily accessible.
Coolant Bottle

Coolant Bottle

Gravity-fed coolant bottle improves cutter life and drilling performance.
Slot Drive Arbor

Slot Drive Arbor

Industrial slot drive arbor provides secure cutter engagement and reliable power transfer.
Two Stage Magnet

Two Stage Magnet

Improved holding power on thin steel
Pilot Light

Pilot Light

Pilot light for low light conditions and greater hole accuracy
Two Year Warranty

Two Year Warranty

American Made & Backed by the Company Who Built It
Electrical / Motor
Electrical System
115V, 50/60 Hz - 9A, 1035W
Motor RPM
450
Voltage
115V
Amperage
9A
Capacity
Annular Cutter Capacity
7/16" - 1-1/2" (12mm - 38mm)
Twist Drill Capacity
1/2" w/ drill chuck
Tapping Capacity
1/2" w/ tapping unit
Depth of Cut
2" (50mm)
Cutter / Mount
"12,000-Series" & Copperhead™ cutters, 3/4" (19mm) shank
Dimensions
Dimensions
18" H x 7-3/4" W x 11-5/8" L (457mm H x 197mm W x 295mm L)
Base Dimensions
3-1/8" W x 6-9/16" L (79mm W x 167mm L)
Magnet Dimensions
3-1/8" W x 6-9/16" L (79mm W x 167mm L)
Magnet Performance
Magnet Dead Lift (1" Plate)
DEAD LIFT: (1" / 25mm Plate): 1750 lb. (794 kg)
Magnet Breakaway (1" Plate)
DRILL POINT BREAKAWAY: (1" / 25mm Plate): 995 lb. (452 kg)
Magnet Dead Lift (3/8" Plate)
DEAD LIFT: (3/8" / 9.5mm Plate): 1310 lb. (594 kg)
Magnet Breakaway (3/8" Plate)
DRILL POINT BREAKAWAY: (3/8" / 9.5mm Plate): 710 lb. (322 kg)
Weight
Weight
30 lb. (13.6 kg)
Shipping Weight
44.1 lb. (20 kg)
  • 0904102 HMD904 115V Coolant
  • 2″ depth “12,000-Series’ cutter Kit (12002)
  • 1/2” drill Chuck and adapter for using twist drills
  • Carrying case
  • Pint of coolant
  • 10730 Safety chain
  • 10565 1/8" Hex wrench for Gib Adjustment
  • 04558 Feed handles (3)
  • 04532 Feed handle knobs (3)
  • 40222 Set screw for cutter installation (2)
  • 24166 7/32" Hex wrench
  • Steel Fabrication
  • Building & Construction
  • Bridge Rebuilding
  • Mining
  • Ship Building
  • Truck, RV & Special Vehicle Build
  • Pipeline, Offshore & Oil Fields
  • Welding Shops
  • Power Utilities
  • Railroad Industries
  • Maintenance Facilities
  • Mobile Repair Shops
  • Machinery Riggers
“12,000-Series” Annular Cutters

“12,000-Series” Annular Cutters

The original mag drill annular cutter, Hougen’s "12,000-Series" are the standard for hole making. Sizes are available up to 3-1/16" in diameter and up to 6" depth of cut.[Learn More]

Learn More →
“12,000-Series” TiN Coated Cutters

“12,000-Series” TiN Coated Cutters

TiN Coated cutters increase tool life, reduce friction, and operate at cooler temperatures. For materials up to 325 BHN or gummy materials. Special Sizes and coatings are available... [Learn More]

Learn More →
Hougen Xtreme Cobalt Annular Cutters

Hougen Xtreme Cobalt Annular Cutters

Built for extreme conditions and tough materials. Made from premium M42 and IronEdge™ coated. Performance, extended tool life, and reliability in the most demanding applications.[Learn More]

Learn More →
Copperhead Carbide Tip Cutters

Copperhead Carbide Tip Cutters

Carbide Tipped Cutters for extended tool life in abrasive & tough materials. Up to 6" deep and diameters to 3".[Learn More]

Learn More →
Hole Enlarging Pilots – “12,000 SERIES”

Hole Enlarging Pilots – “12,000 SERIES”

Sometimes things happen. These tools allow you to take an existing hole and re-drill it to the larger correct size.[Learn More]

Learn More →
RotaMagic Super Concentrated Cutting Fluid

RotaMagic Super Concentrated Cutting Fluid

RotaMagic™ is water soluble, biodegradable cutting lubricant that extends tool life and improves cutter performance.[Learn More]

Learn More →
Slick-Stik Lubricant

Slick-Stik Lubricant

Stick lubricant for easy application, providing superior adhesion to the tool, assuring thorough coverage and increased tool life.[Learn More]

Learn More →
RotaFoam Cutting Fluid

RotaFoam Cutting Fluid

Extremely heavy-duty, high performance foamy lubricant for all types of metals and metal working applications.[Learn More]

Learn More →
RotaGel Cutting Lube

RotaGel Cutting Lube

Environmentally friendly lubricant for all types of metals and metal working applications. Biodegradable & Non-Toxic.[Learn More]

Learn More →
Twist Drill Adapter

Twist Drill Adapter

Drill small diameter holes without removing the arbor. The Twist drill Adapter Kit includes everything you need.[Learn More]

Learn More →
Tapping Kits

Tapping Kits

Tapping holes with your Hougen mag drill is a extremely easy using one of our Tapping Kits.[Learn More]

Learn More →
Pipe Adapter Kits

Pipe Adapter Kits

Drill pipe and tubing with the Hougen Pipe Adapter Kit. Quickly attach to your magnetic drill for positive non-slip centered positioning.[Learn More]

Learn More →
Arbor Extender

Arbor Extender

When extended reach is necessary, Hougen offers 1" and 2" Arbor Extenders that fit 3/4" shank cutter.[Learn More]

Learn More →
Hole Enlarging Pilots – “12,000 SERIES”

Hole Enlarging Pilots – “12,000 SERIES”

Sometimes things happen. These tools allow you to take an existing hole and re-drill it to the larger correct size.[Learn More]

Learn More →
Portable Vac-Pad

Portable Vac-Pad

Use for drilling hole on non-ferrous materials, diamond plate and materials with surface imperfections up to 3mm deep.[Learn More]

Learn More →
