Hougen 0202101 HMD2X2 Low Profile Two Speed Magnetic Drill-115V

Hougen 0202101 HMD2X2 Low Profile Two Speed Magnetic Drill-115V

Authorized Hougen Distributor Fast Shipping Genuine Hougen Parts Expert Tool Support
SKU 0202101
by Hougen Mfg.
Save 10% Save 10%
$ 2,621.50
$ 2,621.50 - $ 2,621.50
$ 2,621.50
$ 2,359.00
$ 2,359.00 - $ 2,359.00
$ 2,359.00

Overview

HMD2X2 Low Profile Two Speed Magnetic Drill

The perfect drill for general metal fabrication and drilling holes in confined spaces.
  • Only 7-5/8" high easily fits into tight spots
  • Lightweight at only 29 lbs (13.2 kg)
  • Telescoping spline arbor for smooth cuts and minimal maintenance
  • Uses standard two flat shank annular cutters
  • Pilot light for low light conditions and greater hole accuracy
  • Two stage magnet. Engages full power only when motor is turnedon which increases magnet life
  • Positive slug ejection
  • High torque two speed gear box
  • Carrying handle
  • Lift detector safety system
  • Ratchet drive feed for confined spaces and convenience
  • Rear mounted controls
  • Carrying case (20213) & ratchet included
  • Two year warranty
Made in USA

Made in USA

Proudly manufactured in the United States for superior quality, durability, and reliability in demanding industrial environments.
Gear Shift

Gear Shift

Two-speed gearbox allows optimal torque and cutting speed for different hole sizes.
Pilot Light

Pilot Light

Pilot light for low light conditions and greater hole accuracy
Two Year Warranty

Two Year Warranty

American Made & Backed by the Company Who Built It
Electrical / Motor
Electrical System
115V, 50/60 Hz - 10A, 1150W
Motor
9A, 1035W (115V), 300/450 RPM
Motor RPM
300/450 RPM
Voltage
115V
Amperage
10A
Capacity
Annular Cutter Capacity
7/16"- 2" (12mm - 50mm)
Depth of Cut
2" (50mm)
Cutter / Mount
"12,000-Series" & Copperhead™ cutters, 3/4" (19mm) shank
Dimensions
Base Dimensions
3-1/2" W x 8" L (89mm W x 203mm L)
Magnet Dimensions
3-1/2" W x 8" L (89mm W x 203mm L)
Magnet Performance
Magnet Dead Lift (1" Plate)
Dead Lift 1960 lb. (889 kg)
Magnet Breakaway (1" Plate)
Drillpoint Breakaway 905 lb. (411 kg)
Magnet Dead Lift (3/8" Plate)
Dead Lift 1405 lb. (637 kg)
Magnet Breakaway (3/8" Plate)
Drillpoint Breakaway 640 lb. (290 kg)
Weight
Weight
29.2 lb. (13.2 kg)
Shipping Weight
38.2 lb. (17.3 kg)
  • Unmatched Power & Torque
  • The HMD2X2 has a true 2" x 2" hole capacity while maintaining a constant height coupled with a two speed gearbox for improved tool life and high torque throughout the power band.
  • Power & performance for general metal fabrication and drilling holes in confined spaces
  • 0202101 HMD2X2 115V
  • Carrying Case (20213)
  • Ratchet included
  • Safety strap
  • Slick-Stik lubricant
  • Steel Fabrication
  • Building & Construction
  • Bridge Rebuilding
  • Mining
  • Ship Building
  • Truck, RV & Special Vehicle Build
  • Pipeline, Offshore & Oil Fields
  • Welding Shops
  • Power Utilities
  • Railroad Industries
  • Maintenance Facilities
  • Mobile Repair Shops
  • Machinery Riggers
“12,000-Series” Annular Cutters

“12,000-Series” Annular Cutters

The original mag drill annular cutter, Hougen’s "12,000-Series" are the standard for hole making. Sizes are available up to 3-1/16" in diameter and up to 6" depth of cut.[Learn More]

Learn More →
“12,000-Series” TiN Coated Cutters

“12,000-Series” TiN Coated Cutters

TiN Coated cutters increase tool life, reduce friction, and operate at cooler temperatures. For materials up to 325 BHN or gummy materials. Special Sizes and coatings are available... [Learn More]

Learn More →
Hougen Xtreme Cobalt Annular Cutters

Hougen Xtreme Cobalt Annular Cutters

Built for extreme conditions and tough materials. Made from premium M42 and IronEdge™ coated. Performance, extended tool life, and reliability in the most demanding applications.[Learn More]

Learn More →
Copperhead Carbide Tip Cutters

Copperhead Carbide Tip Cutters

Carbide Tipped Cutters for extended tool life in abrasive & tough materials. Up to 6" deep and diameters to 3".[Learn More]

Learn More →
Hole Enlarging Pilots – “12,000 SERIES”

Hole Enlarging Pilots – “12,000 SERIES”

Sometimes things happen. These tools allow you to take an existing hole and re-drill it to the larger correct size.[Learn More]

Learn More →
RotaMagic Super Concentrated Cutting Fluid

RotaMagic Super Concentrated Cutting Fluid

RotaMagic™ is water soluble, biodegradable cutting lubricant that extends tool life and improves cutter performance.[Learn More]

Learn More →
Slick-Stik Lubricant

Slick-Stik Lubricant

Stick lubricant for easy application, providing superior adhesion to the tool, assuring thorough coverage and increased tool life.[Learn More]

Learn More →
RotaFoam Cutting Fluid

RotaFoam Cutting Fluid

Extremely heavy-duty, high performance foamy lubricant for all types of metals and metal working applications.[Learn More]

Learn More →
RotaGel Cutting Lube

RotaGel Cutting Lube

Environmentally friendly lubricant for all types of metals and metal working applications. Biodegradable & Non-Toxic.[Learn More]

Learn More →
Twist Drill Adapter

Twist Drill Adapter

Drill small diameter holes without removing the arbor. The Twist drill Adapter Kit includes everything you need.[Learn More]

Learn More →
Arbor Extender

Arbor Extender

When extended reach is necessary, Hougen offers 1" and 2" Arbor Extenders that fit 3/4" shank cutter.[Learn More]

Learn More →
Hole Enlarging Pilots – “12,000 SERIES”

Hole Enlarging Pilots – “12,000 SERIES”

Sometimes things happen. These tools allow you to take an existing hole and re-drill it to the larger correct size.[Learn More]

Learn More →
