Additional Details
Uniform-torque motor for demanding core drilling.
High concentricity and positive slug ejection due to special bore spindle guides.
Solid, massive construction in die-cast aluminum for work under difficult conditions.

Features
Power consumption    1,050 W
Power output    530 W
Cutter holder    3/4" straight shank
Full load speed    330 rpm
No load speed    480 rpm
HSS cutter max. dia.    1-1/2 [38] in[mm]
Cutter max. drilling depth    2 [50] in[mm]
Twist drill max. dia.    1/2 [12] in[mm]
Stroke    2-9/16 [65] in[mm]
Magnetic holding force    2023 [9,000] lbs[N]
Cable with plug    12.5 [3.8] ft[m]
Weight    31.75 [14.40] lbs[kg]
